Attributes
Description
Compliant
standard
OC-3c/STM-1, IETF RFC2684
Link protocol
ATM
Network
protocol
ATM Cell Transfer
Table 6-300 Attributes of 155 M SFP optical modules
Attributes
Description
Maximum
transmission
distance
2 km (1.24 mi.)
15 km (9.32
mi.)
40 km (24.86
mi.)
80 km (49.71
mi.)
Center
wavelength
1310 nm
1310 nm
1310 nm
1550 nm
Minimum
transmitting
power
-19.0 dBm
-15.0 dBm
-5.0 dBm
-5.0 dBm
Maximum
transmitting
power
-14.0 dBm
-8.0 dBm
0 dBm
0 dBm
Receiving
sensitivity
-30.0 dBm
-31.0 dBm
-37.0 dBm
-37.0 dBm
Overload
optical power
-14.0 dBm
-8.0 dBm
-10.0 dBm
-10.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
Technical Specifications
Table 6-301 lists the technical specifications of the 8-Port OC-3c/STM-1c ATM-SFP Flexible
Card.
Table 6-301 Technical specifications of the 8-Port OC-3c/STM-1c ATM-SFP Flexible Card
Item
Specifications
Silkscreen of the board
name
P50-8×OC3c/STM1c ATM-SFP
Power consumption
(typical value)
About 29 W
