Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
382
Table 6-319 Indicators and button on the panel of the LPUF-40
Indicator/Button
Description
OFL button
It is a button indicating the removal of a board. Before removing a
board, you need to press and hold the OFL button for about 5s till
the OFL indicator is on.
OFL indicator (red)
If the indicator is on, you can remove the board.
RUN indicator
(green)
If the indicator blinks once every 2s (0.5 Hz), the LPU is in the
normal state.
Technical Specifications
Table 6-320 lists the technical specifications of the LPUF-40.
Table 6-320 Technical specifications of the LPUF-40
Item
Specifications
Dimensions (width x depth x
height)
399 mm x 551 mm x 41 mm ( 15.71 in. x 21.69 in. x
1.61 in. )
Power consumption (typical value)
About 280W
Heat dissipation
908 BTU/hour
Board weight
About 7 kg ( 15.44 lb )
Earliest software version
V600R001
Product Specifications
Table 6-321 lists the product specifications of the LPUF-40.
Table 6-321 Product specifications of the LPUF-40
Item
Specifications
Reliability and
availability
Software features

The LPUF-40-A supports all software features.

The LPUF-40-B does not support L3VPN, MVPN, or IPv6.

The LPUF-40-E does not support PPPoE or L2TP.

The LPUF-40 with 2-Port 10GBase LAN/WAN-XFP Flexible
Card A, 20-Port 100/1000Base-X-SFP Flexible Card A supports
1588v2.

The LPUF-40 with 20-Port 100/1000Base-X-SFP Flexible Card
B, 2-Port 10GBase LAN/WAN-XFP Flexible Card B supports
BRAS access.

The LPUF-40 with 20-Port 1000Base-X-SFP Flexible Card
