Panel
Table 6-322 describes the indicators on the panel.
Table 6-322 Indicators on the panel of the 20-port 100/1000Base-X-SFP Flexible Card
Indicator
Description
STATUS
indicator (green)
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state.
If the indicator blinks twice every 1s (2 Hz), the FPIC is in the alarm
state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up.
If the indicator is blinking, the data is being read or written.
If the indicator is off, the link is Down.
Interface Attributes
Table 6-323 lists the interface attributes of the 20-port 100/1000Base-X-SFP flexible card.
Table 6-323 Interface attributes of the 20-port 100/1000Base-X-SFP flexible card
Attributes
Description
Connector type
LC/PC
Optical interface
attributes
Compliant with the selected SFP optical module.
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Table 6-324 Attributes of 100M SFP optical modules
Attributes
Description
Maximum
transmission
distance
2 km ( 1.24
mi. )
15 km ( 9.32
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center wavelength
1310 nm
1310 nm
1310 nm
1550 nm
Minimum
transmitting power
-19.0 dBm
-15.0 dBm
-5.0 dBm
-5.0 dBm
Maximum
transmitting power
-14.0 dBm
-8.0 dBm
0 dBm
0 dBm
