Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
395
Attributes
Description
Overload
optical power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical module supports two types of multi-mode optical fibers
with different cores. Table 6-343 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type, which is not delivered by
Huawei.If this type of optical fiber is required, you need to purchase it additionally.
Table 6-343 Transmission distance of 10G XFP optical modules
Core(μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2-300 ( 1.24 - 186.42 )
50
500
2-82 ( 1.24 - 50.95 )
62.5
200
2-33 ( 1.24 - 20.51 )
Technical Specifications
Table 6-344 lists the technical specifications of the 2-port 10GBase LAN/WAN-XFP FPIC.
Table 6-344 Technical specifications of the 2-port 10GBase LAN/WAN-XFP FPIC
Item
Specifications
Silkscreen of the board
name
P40-2x10GBase LAN/WAN-XFP
Power consumption (typical
value)
About 12 W
Heat dissipation
39 BTU/hour
Board weight
About 0.5 kg ( 1.10 lb )
Dimensions (width x depth
x height)
145 mm x 180mm x 40mm ( 5.71 in. x 7.09 in. x 1.57 in. )
Connector type
LC
Earliest software version
V600R001
