Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
397
Panel
Table 6-346 describes the indicators on the panel.
Table 6-346 Indicators on the panel of the 2-Port 10GBase LAN/WAN-XFP Flexible Card
A(Supporting 1588v2)
Indicator
Description
STATUS
indicator (green)
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-347 lists the interface attributes of the 2-Port 10GBase LAN/WAN-XFP Flexible Card
A(Supporting 1588v2).
Table 6-347 Interface attributes of the 2-Port 10GBase LAN/WAN-XFP Flexible Card
A(Supporting 1588v2)
Attributes
Description
Connector type
LC/PC
Optical
interface
attributes
Compliant with the selected XFP optical module. (for the attributes of
XFP modules, see Table 6-348)
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network
protocol
IP
Table 6-348 Attributes of 10G XFP optical modules
Attributes
Description
Maximum
transmission
distance
0.3 km ( 0.19
mi. )
10 km ( 6.21
mi. )
40 km ( 24.86
mi. )
80 km ( 49.71
mi. )
Center
wavelength
850 nm
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-7.3 dBm
-6.0 dBm
-1.0 dBm
0 dBm
