Indicator
Description
FPIC is in the alarm state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-359 lists the interface attributes of the 20-Port 1000Base-X-SFP Flexible Card
E(P40-E).
Table 6-359 Interface attributes of the 20-Port 1000Base-X-SFP Flexible Card E(P40-E)
Attributes
Description
Optical interface
attributes
Compliant with the selected SFP optical module.
Working mode
Full-duplex
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Table 6-360 Attributes of 1000M SFP optical modules
Attributes
Description
Maximum
transmission
distance
0.5 km
( 0.31
mi. )
10 km
( 6.21
mi. )
40 km
( 24.86
mi. )
40 km
( 24.86
mi. )
80
km( 49.
71 mi. )
100 km
( 62.14
mi. )
Center
wavelength
850 nm
1310 nm
1310 nm
1550 nm
1550
nm
1550 nm
Minimum
transmitting
power
-9.5 dBm
-9.5 dBm
-4.5 dBm
-4.0 dBm
-2.0
dBm
0 dBm
Maximum
transmitting
power
-2.5 dBm
-3.0 dBm
3.0 dBm
1.0 dBm
5.0
dBm
5.0 dBm
Receiving
sensitivity
-17.0
dBm
-20.0
dBm
-22.5
dBm
-21.0
dBm
-23.0
dBm
-30.0
dBm
Overload optical
power
0 dBm
-3.0 dBm
-3.0 dBm
-3.0 dBm
-3.0
dBm
-9.0 dBm
Optical fiber type
Multi-mo
de
Single-m
ode
Single-m
ode
Single-m
ode
Single-
mode
Single-m
ode
