Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
409
Table 6-368 Technical specifications of the 2-Port 10GBase LAN/WAN-XFP Flexible Card E
Item
Specifications
Silkscreen of the board
name
P40-2x10GBase LAN/WAN-XFP-E
Power consumption
(typical value)
40W
Heat dissipation
130 BTU/hour
Board weight
About 0.52 kg ( 1.15 lb )
Dimensions (width x
depth x height)
178 mm x 125 mm x 35 mm ( 7.01 in. x 4.92 in. x 1.38 in. )
Connector type
LC/PC
Earliest software version
V600R003C05
Product Specifications
Table 6-369 lists the product specifications of the 2-Port 10GBase LAN/WAN-XFP Flexible
Card E.
Table 6-369 Product specifications of the 2-Port 10GBase LAN/WAN-XFP Flexible Card E.
Item
Specifications
Supported protocol
and service
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
PTP (supported by the system software package of V600R003 and
later versions)
BRAS support
Interface type
XFP
Reliability and
availability
Hardware feature

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C
Short-term ambient temperature: -5°C to +55°C
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
Storage conditions
Storage temperature: -40°C to +70°C
Storage humidity: 0% to 95%
