Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
433
Attributes
Description
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical transceiver supports two types of multi-mode optical fibers
with different cores. Table 6-407 lists the relationship between the core, the modal/bandwidth,
and the transmission distance. During configuration, the length of optical fibers is restricted
by the transmission distance. In addition, the optical fiber with the 50-um core and
2000-MHz*km modal/bandwidth is a special type. If this type of optical fibers are required,
you need to purchase it additionally.
Table 6-407 The transmission distance of 10G XFP optical modules
Core Fiber(μm)
Modal/Bandwidth(Mhz*
km)
Transmission
distance(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
Technical Specifications
Table 6-408 lists the technical specifications of the 4-port 10GBase LAN/WAN-XFP
Integrated Line Processing Unit.
Table 6-408 Technical specifications of the 4-port 10GBase LAN/WAN-XFP Integrated Line
Processing Unit
Item
Specifications
Silkscreen
of the
board
name
LPUI-41
4×10GBase LAN/WAN-XFP
Power
consumpti
on(Typica
l value)
About 155 W
Heat
dissipation
528.86 BTU/hour
Board
weight
About 6.62 kg ( 14.60 lb )
Dimensio
ns (width
x depth x
height)
399 mm x 551 mm x 41 mm ( 15.71 in. x 21.69 in. x 1.61 in. )
