Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
487
Attributes
Description
transmitting
power
Maximum
transmitting
power
-1.3 dBm
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-7.5 dBm
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload
optical power
-1.0 dBm
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber
type
Multi-mode
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical module transceiver supports two types of multi-mode
optical fibers with different cores. Table 6-486 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type.If this type of optical fiber is
required, you need to purchase it additionally.
Table 6-486 The transmission distance of 10G XFP optical modules
Core (μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
Technical Specifications
Table 6-487 lists the technical specifications of the 4-port 10GBase LAN/WAN-XFP Line
Processing Unit S.
Table 6-487 Technical specifications of the 4-port 10GBase LAN/WAN-XFP Line Processing
Unit S
Item
Specifications
Silkscreen of the board
name
LPUS-20
4 x 10GBase LAN/WAN - XFP
Power consumption
(typical value)
About 241 W
Heat dissipation
782 BTU/hour
