Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
500
Technical Specifications
Table 6-506 lists the technical specifications of the 1-port 10GBase LAN/WAN-XFP FPIC.
Table 6-506 Technical specifications of the 1-port 10GBase LAN/WAN-XFP FPIC
Item
Specifications
Silkscreen of the board
name
1 x 10GBase LAN/WAN
Power consumption
(typical value)
About 18 W
Heat dissipation
58 BTU/hour
Board weight
About 0.5 kg ( 1.10 lb )
Dimensions (width x
depth x height)
145 mm x 180mm x 40mm ( 5.71 in. x 7.09 in. x 1.57 in. )
Connector type
LC
Earliest software
version
V300R003
Product Specifications
Table 6-507 lists the product specifications of the 1-port 10GBase LAN/WAN-XFP FPIC.
Table 6-507 Product Specifications of the 1-port 10GBase LAN/WAN-XFP FPIC.
Item
Specifications
Supported protocol
and service
IP
Interface type
XFP
Reliability and
availability
Hardware feature

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C ( 32°F to 113°F )
Short-term ambient temperature: -5°C to +55°C ( 23°F to 131°F )
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
Storage conditions
Storage temperature: -40°C to +70°C ( -40°F to 158°F )
Storage humidity: 0% to 95%
