HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 6-181 Panel appearance of the 1-port 10GBase LAN/WAN-XFP Flexible Card B
Table 6-514 Indicators on the panel of the 1-port 10GBase LAN/WAN-XFP Flexible Card B
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-515 lists the interface attributes of the 1-port 10GBase LAN/WAN-XFP Flexible Card
B.
Table 6-515 Interface attributes of the 1-port 10GBase LAN/WAN-XFP Flexible Card B
Optical
interface
attributes
Compliant with the selected XFP optical module.(for the attributes of
XFP modules, see Table 6-516)
