HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 6-187 Panel appearance of the 12-port 100/1000Base-SFP Flexible Card A(Supporting
1588v2)
Table 6-533 Indicators on the panel of the 12-port 100/1000Base-SFP Flexible Card A(Supporting
1588v2)
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-534 lists the interface attributes of the 12-port 100/1000Base-SFP Flexible Card
A(Supporting 1588v2).
Table 6-534 Interface attributes of the 12-port 100/1000Base-SFP Flexible Card A(Supporting
1588v2)
Optical interface
attributes
Compliant with the selected SFP optical module
