Indicator
Description
FPIC is in the alarm state.
LINK/ACT
indicator
If the indicator is on, the link is Up. If the indicator is blinking, the
data is being read or written. If the indicator is off, the link is Down.
Interface Attributes
Table 6-546 lists the interface attributes of the 10-port 1000Base-X-SFP Flexible Card E.
Table 6-546 Interface attributes of the 10-port 1000Base-X-SFP Flexible Card E
Attributes
Description
Connector type
LC/PC
Optical interface
attributes
Compliant with the selected SFP optical module
Working mode
Full-duplex
Compliant
standard
IEEE 802.3-2002
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Table 6-547 Attributes of 1000M SFP optical modules
Attributes
Description
Maximum
transmission
distance
0.5 km
( 0.31
mi. )
10 km
( 6.21
mi. )
40 km
( 24.86
mi. )
40 km
( 24.86
mi. )
80 km
( 49.71
mi. )
100 km
( 62.14
mi. )
Center
wavelength
850 nm
1310 nm
1310 nm
1550 nm
1550
nm
1550 nm
Minimum
transmitting
power
-9.5 dBm
-9.5 dBm
-4.5 dBm
-4.0 dBm
-2.0
dBm
0 dBm
Maximum
transmitting
power
-2.5 dBm
-3.0 dBm
3.0 dBm
1.0 dBm
5.0
dBm
5.0 dBm
Receiving
sensitivity
-17.0
dBm
-20.0
dBm
-22.5
dBm
-21.0
dBm
-23.0
dBm
-30.0
dBm
Overload optical
power
0 dBm
-3.0 dBm
-3.0 dBm
-3.0 dBm
-3.0
dBm
-9.0 dBm
