Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
554
The 10G XFP multi-mode optical module transceiver supports two types of multi-mode
optical fibers with different cores. Table 6-590 shows the relationship between the core, the
modal/bandwidth, and the transmission distance. During configuration, the length of optical
fibers is restricted by the transmission distance. In addition, the optical fiber with the 50-um
core and 2000-MHz*km modal/bandwidth is a special type, which is not delivered by Huawei.
If this type of optical fiber is required, you need to purchase it additionally.
Table 6-590 The transmission distance of 10G XFP optical modules
Core (μm)
Modal/Bandwidth(Mhz*
km)
Transmission Distance
(km)
50
2000
2-300 ( 1.24 - 186.42 )
50
500
2-82 ( 1.24 - 50.95 )
62.5
200
2-33 ( 1.24 - 20.51 )
Technical Specifications
Table 6-591 lists the technical specifications of the 1-port OC-192c/STM-64c POS-XFP
FPIC.
Table 6-591 Technical specifications of the 1-port OC-192c/STM-64c POS-XFP FPIC
Item
Specifications
Silkscreen of the
board name
FPIC-1 x OC192-POS
Power
consumption
(typical value)
About 22 W
Heat dissipation
71 BTU/hour
Board weight
About 0.6 kg ( 1.32 lb )
Dimensions
(width x depth x
height)
169 mm x 200 mm x 37 mm ( 6.65 in. x 7.87 in. x 1.46 in. )
Connector type
LC
Earliest software
version
when the FPIC is used together with the LPUF-10,the earliest software
version is V300R003
when the FPIC is used together with the LPUF-50,the earliest software
version is V600R006C00
Product Specifications
Table 6-592 lists the product specifications of the 1-Port OC-192c/STM-64c POS-XFP
Flexible Card.
