Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
561
Attributes
Description
type
Technical Specifications
Table 6-601 lists the technical specifications of the 2-port OC-48c/STM-16c POS-SFP FPIC.
Table 6-601 Technical specifications of the 2-port OC-48c/STM-16c POS-SFP FPIC
Item
Specifications
Silkscreen of the
board name
FPIC-2 x OC48-POS
Power consumption
(typical value)
About 19 W
Heat dissipation
62 BTU/hour
Board weight
About 0.50 kg ( 1.10 lb )
Dimensions (width x
depth x height)
169 mm x 200 mm x 18.5 mm ( 6.65 in. x 7.87 in. x 0.73 in. )
Connector type
LC
Earliest software
version
when the FPIC is used together with the LPUF-10,the earliest
software version is V300R006
when the FPIC is used together with the LPUF-50,the earliest
software version is V600R006C00
Product Specifications
Table 6-602 lists the product specifications of the 2-port OC-48c/STM-16c POS-SFP FPIC.
Table 6-602 Product specifications of the 2-port OC-48c/STM-16c POS-SFP FPIC.
Item
Specifications
Supported protocol
and service
PPP or HDLC
Interface type
SFP
Reliability and
availability
Hardware feature

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C ( 32°F to 113°F )
