Technical Specifications
Table 6-621 lists the technical specifications of the 4-port OC-3c/STM-1c POS-SFP FPIC.
Table 6-621 Technical specifications of the 4-port OC-3c/STM-1c POS-SFP FPIC
Item
Specifications
Silkscreen of the
board name
FPIC-4×OC3-POS
Power consumption
(typical value)
About 18 W
Heat dissipation
58 BTU/hour
Board weight
About 0.50 kg ( 1.10 lb )
Dimensions (width x
depth x height)
169 mm x 200 mm x 18.5 mm ( 6.65 in. x 7.87 in. x 0.73 in. )
Connector type
LC
Earliest software
version
V300R006
Product Specifications
Table 6-622 lists the product specifications of the 4-port OC-3c/STM-1c POS-SFP FPIC.
Table 6-622 Product specifications of the 4-port OC-3c/STM-1c POS-SFP FPIC.
Item
Specifications
Supported protocol
and service
PPP or HDLC
Interface type
SFP
Reliability and
availability
Hardware feature

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C ( 32°F to 113°F )
Short-term ambient temperature: -5°C to +55°C ( 23°F to 131°F )
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
Storage conditions
Storage temperature: -40°C to +70°C ( -40°F to 158°F )
Storage humidity: 0% to 95%
