HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
598
Attributes
Description
Electrical
interface
attribute
CE1/CT1
Working mode
Full-duplex
Link protocol
HDLC, PPP, MLPPP, cRTP
Network
protocol
IP
Technical Specifications
Table 6-658 lists the technical specifications of the 24-port channelized E1/T1-DB100 FPIC.
Table 6-658 Technical specifications of the 24-port channelized E1/T1-DB100 FPIC
Item
Specifications
Silkscreen of the
board name
24xcE1/cT1-DB 100
Power
consumption
(typical value)
About 29 W
Heat dissipation
94 BTU/hour
Board weight
About 0.5 kg ( 1.10 lb )
Dimensions (width
x depth x height)
169 mm x 200 mm x 18.5 mm ( 6.65 in. x 7.87 in. x 0.73 in. )
Connector type
RJ48
Earliest software
version
when the FPIC is used together with the LPUF-10,the earliest
software version is V300R006
when the FPIC is used together with the LPUF-50,the earliest
software version is V600R006C00
Product Specifications
Table 6-659 lists the product specifications of the 24-port channelized E1/T1-DB100 FPIC.
Table 6-659 Product Specifications of the 24-port channelized E1/T1-DB100 FPIC.
Item
Specifications
Supported protocol
and service
PPP, MPPP, HDLC, and cRTP
ATM AAL0, IMA, and PWE3
