HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Power Supply Distance Shorter Than 15 m ( 49.21 ft )
If the power supply distance is shorter than 15 m ( 49.21 ft ), use the 16 mm^2 ( 0.02 in.^2 )
power cable to connect the NE40E and the power distribution cabinet.Table 7-4 lists the cable
terminals and cable types.
Table 7-4 Cables used when the power supply distance is shorter than 15 m ( 49.21 ft )
Naked Crimping Terminal,JG2,16mm^2,M6,95A,Tin Plated,for OEM
Naked Crimping Terminal,OT,16mm^2,M8,Tin Plating,Naked Ring
Terminal
Wire,450/750V,227 IEC 02(RV)16mm^2,blue,85A
Wire,450/750V,227 IEC 02(RV)16mm^2,black,85A
Power Supply Distance Longer Than 15 m ( 49.21 ft ) and Shorter Than 25 m
( 82.02 ft )
If the power supply distance is longer than 15 m ( 49.21 ft ) and shorter than 25 m ( 82.02 ft ),
use the 25 mm^2 ( 0.04 in.^2 ) power cable to connect the NE40E and the power distribution
cabinet. Table 7-5 lists the cable terminals and cable types..
Table 7-5 Cables for Power Distance More than 15 m ( 49.21 ft ) but Less than 25 m ( 82.02 ft )
Naked Crimping Connector,JG2,25mm^2,M6,150A,Tin Plating,For OEM
Naked Crimping Terminal,OT,25mm^2,M8,Tin Plating,Naked Ring
Terminal
Wire,450/750V,227 IEC 02(RV)25mm^2,blue
Wire,450/750V,227 IEC 02(RV)25mm^2,black,110A
Power Supply Distance Longer Than 25 m ( 82.02 ft ) and Shorter Than 35 m
( 114.83 ft )
If the power supply distance is longer than 25 m ( 82.02 ft ) and shorter than 35 m ( 114.83 ft ),
use the 35 mm^2 ( 0.05 in.^2 ) power cable to connect the NE40E and the power distribution
cabinet.Table 7-6 lists the cable terminals and cable types.
Table 7-6 Cables used when the power supply distance is longer than 25 m ( 82.02 ft ) and shorter
than 35 m ( 114.83 ft )
Naked Crimping Connector,JG2,34.3mm^2,M6(1/4"),134A,Tin
