Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
7 Cables
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
621
Item
Description
protection layer -
diameter of the internal
insulation - diameter of
the internal conductor
( 0.01 in. )
120-ohm
cable
Type
Symmetrical twisted cable
-120ohm-SEYPVPV-0.4mm-26AWG-2
pairs-Pantone 430U
Diameter of the internal
conductor
0.4 mm ( 0.02 in. )/26AWG
Available length
30 m ( 98.42 ft )
Table 7-26 lists the technical specifications of the two-channel 75-ohm/120-ohm clock
transfer cable.
Table 7-26 Technical specifications of the two-channel clock transfer cable
Item
Description
X1/X2 connector
Coaxial connector-SMB plug-75 ohm inline female
75-ohm
cable
Type
Coaxial cable-75 ohm-3.9 mm-2.1 mm-0.34
mm-shield
Diameter of the
protection layer -
diameter of the internal
insulation - diameter of
the internal conductor
3.9 mm ( 0.15 in. )- 2.1 mm ( 0.08 in. )- 0.34 mm
( 0.01 in. )
120-ohm
cable
Type
Symmetrical twisted cable
-120ohm-SEYPVPV-0.4mm-26AWG-2
pairs-Pantone 430U
Diameter of the internal
conductor
0.4 mm ( 0.02 in. )/26AWG
Available length
30 m ( 98.42 ft )
Table 7-27 lists the technical specifications of the 120-ohm trunk cable.
Table 7-27 Technical specifications of the 120-ohm trunk cable
Item
Description
120-ohm
cable
Connector
Network interface connector-8 PIN-8 bit-shielded-crystal
model plug
Type
Cable,120ohm,1E1,0.4mm,MP8-II,120CC4P0.4P430U(S),MP
8-II,Expert 2.0
