Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
3 NE40E-X8 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
69
Table 3-22 lists the 10Base-T/100Base-TX/1000Base-T-RJ45 interface attributes.
Table 3-22 10Base-T/100Base-TX/1000Base-T-RJ45 interface attributes
Attribute
Description
Connector type
RJ45
Operation mode
10M/100M/1000M auto-sensing interfaces, supporting half-duplex and
full-duplex modes
Standard
compliance
IEEE 802.3-2002
Cable
specification
Category 5 unshielded twisted pair (UTP) cables recommended when
the interface rate is 10 Mbit/s or 100 Mbit/s; super category 5 Shielded
Twisted Pair (STP) cables recommended when the interface rate is
1000 Mbit/s
Table 3-23 lists the console interface attributes.
Table 3-23 Console interface attributes
Attribute
Description
Connector type
RJ45
Operation mode
Duplex Universal Asynchronous Receiver/Transmitter (UART)
Electrical
attribute
RS-232
Baud rate
9600 bit/s (default value), which can be changed as required
Data equipment
type
DCE (Data Circuit-terminating Equipment)
Cable
specification
8-core shielded cable
Table 3-24 lists the AUX interface attributes.
Table 3-24 AUX interface attributes
Attribute
Description
Connector type
RJ45
Operation mode
Duplex UART
Electrical
attribute
RS-232
