4. Run:
vrrp6 vrid virtual-router-id1 track admin-vrrp6 interface interface-type
interface-number vrid virtual-router-id2
The member VRRP6 backup group is bound to the mVRRP6 backup group.
After the member VRRP6 backup group is bound to the mVRRP backup group, the
state machine of the member VRRP6 backup group becomes dependent. That is, the
member VRRP6 backup group deletes the protocol timer, and no longer sends or
receives packets, and implements its state machine by directly copying the status of
the mVRRP6 backup group. A member VRRP6 backup group can be bound to only
one mVRRP6 backup group.
NOTE
Only a single member VRRP6 backup group can be configured on a single interface.
----End
6.8.4 Checking the Configuration
By viewing all bindings in an mVRRP backup group, you can check whether the configurations
are successful.
Prerequisite
The configurations of the mVRRP backup groups function are complete.
Procedure
l Run the display vrrp binding admin-vrrp [ interface interface-type interface-number ]
[ vrid virtual-router-id ] command to check all binding information about the mVRRP
backup group.
l Run the display vrrp binding admin-vrrp [ interface interface-type1 interface-
number1 ] [ vrid virtual-router-id ] member-vrrp [ interface interface-type2 interface-
number2 ] [ vrid virtual-router-id ] command to check the binding between the mVRRP
backup group and the member VRRP backup groups.
l Run the display vrrp binding admin-vrrp [ interface interface-type1 interface-
number1 ] [ vrid virtual-router-id ] member-interface [ interface interface-type2
interface-number2 ] command to check the binding between the mVRRP backup group
and member VRRP backup groups.
l Run the display vrrp admin-vrrp command to check the status of all mVRRP backup
groups in the current configuration.
----End
Example
After the configuration, you can run the display vrrp binding admin-vrrp command to view
all binding information about the member VRRP backup group, interface member, and PW
member.
<Quidway> display vrrp binding admin-vrrp
Interface: Vlanif 100, admin-vrrp vrid: 6, state: Master
Member-vrrp number: 1
Interface: Vlanif 200, vrid: 8, state: Master
Quidway S6700 Series Ethernet Switches
Configuration Guide - Reliability 6 VRRP and VRRP6 Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
245
