6.11.4 Example for Configuring VRRP6 on an Interface
Networking Requirements
Switch A and Switch B elect a master device according to the configured priorities in a VRRP6
group.
Once the master device is determined in the group, only the master device responds to IPv6
messages. If the master device goes down, the backup device becomes the master device and
the hosts in the private network can still communicate with external networks.
The configured virtual address can be same as the address of any physical interface of the Switch
A or Switch B.
Figure 6-6 Networking of VRRP6
Ethernet
HostB
HostA
Virtual IP Address:
2000::1
XGE0/0/1
Vlanif100
2000::2
XGE0/0/2
Vlanif100
2000::3
SwitchA
SwitchB
Master
Backup
Network
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure IPv6 addresses for interfaces.
2. Configure virtual IPv6 addresses.
Data Preparation
To complete the configuration, you need the following data:
l VRRP6 group ID
l Priorities of the Switches in the VRRP6 group
l IPv6 addresses to be configured for interfaces
l Virtual IPv6 addresses to be configured for interfaces in the VRRP6 group
Procedure
Step 1 Enable IPv6 forwarding.
# Configure SwitchA.
Quidway S6700 Series Ethernet Switches
Configuration Guide - Reliability 6 VRRP and VRRP6 Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
264
