HSI: indicates High Speed Internet
In the preceding figure, the IPTV service and HSI service are respectively carried in two domains
that share the same RRPP ring. By applying RRPP multi-instance, you can realize balanced
traffic loads for both services, that is, the IPTV service is carried in domain 1, and the HSI service
is carried in domain 2.
NOTE
Only either RRPP or STP can be configured on one port.
RRPP has no auto-selection mechanism. Ring detection and protection can be enabled in the corresponding
protocol only when each node in the ring is correctly configured. Therefore, make sure that all the
configurations are correct.
Pre-configuration Tasks
Before configuring RRPP multi-instance, complete the following tasks:
l Establishing the ring networking
l Configuring link attributes for interfaces
Data Preparation
To configure RRPP multi-instance, you need the following data.
No.
Data
1 IDs of RRPP domains
2 IDs of control VLANs in RRPP domains
3 IDs of protected VLANs in RRPP domains
4 IDs of RRPP rings in RRPP domains
5 Names of the ports in RRPP rings
6 (Optional) IDs of the ring groups
7 (Optional) Delay for link restoration
8 (Optional) Values of the Hello timer and Fail timer in RRPP domains
3.4.2 Creating Instances
Context
Do as follows on the S6700 that you want to add to an RRPP domain with multiple instances.
Quidway S6700 Series Ethernet Switches
Configuration Guide - Reliability 3 RRPP Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
63
