l Configuring QoS CAR if you want to test QoS CAR on the network
For the configuration procedure, see the Quidway S6700 Series Ethernet Switches
Configuration Guide - QoS.
Data Preparation
To configure local MAC swap loopback, you need the following data.
No. Data
1 Type and number of the interface where the local MAC swap loopback test needs to
be performed
2 Type and number of the outbound interface that sends loopback packets to the tester
3 ID of the VLAN that the interfaces belong to
4 (Optional) Inner VLAN ID
5 Loopback timeout period
7.3.2 Configuring Local MAC Swap Loopback
A local MAC swap loopback test checks connectivity and performance of the network between
a tester and a tested switch, and performance of the tested switch.
Context
Before performing a local MAC swap loopback test, configure the source MAC address,
destination MAC address, and VLAN ID of test packets on the S6700. Only the packets with
the specified source MAC address, destination MAC address, and VLAN ID are looped back.
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
interface interface-type interface-number
The interface view is displayed.
MAC swap loopback tests cannot be performed on an Eth-Trunk interface or its member
interfaces.
Step 3 Run:
loopback local swap-mac source-mac source-mac-address dest-mac dest-mac-address
vlan vlan-id [ inner-vlan inner-vlan-id ] interface interface-type interface-
number [ timeout { time-value | none } ]
Local MAC swap loopback is configured.
Quidway S6700 Series Ethernet Switches
Configuration Guide - Reliability 7 MAC Swap Loopback Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
275
