Figure 3-16 Removing the cabinet rear door
Step 4 Remove the hinges and connecting kits from the UPS rear door and remove the
ground cable.
Put aside the hinges and connecting kits as they are needed in later installation.
UPS5000-E-(30 kVA–180 kVA)
User Manual (Integrated UPS) 3 Installation
Issue 02 (2022-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 63
