UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-58 Connecting the ground cables
Step 11 Connect power cables.
Dual mains
Remove the copper bars between mains and bypass input terminals, as shown in Figure
3-48.
Figure 3-59 shows power cables routed from the bottom by removing small covers, as an
example.
