Chapter 2 • System Control Center
24
1037073-0001 Revision E
Transmission Info page
The Transmission Info page (Figure 19) displays information
about data transmissions from the remote terminal.
•
Transmit Status – Reports the status of the transmit data path.
Clicking the blue status message displays corresponding help
information.
•
Number of Successful Transmissions – Reports the number
of successful transmissions (frames) to the satellite.
•
Number of Failed Transmissions – Reports the number of
frames that could not be sent. A continuously increasing
value indicates a problem with transmitting. However, if a
low non-increasing value is displayed and the system is
functioning, there is no reason for concern. You do not need
to troubleshoot or contact your service provider.
•
Number of Packets submitted for transmission – Indicates the
total number of data packets transmitted.
System Info page
The System Info page shown in Figure 20 has four sections:
HN7000S Info, Satellite, Transmit Radio Info, and Software
Figure 19: Transmission Information page
