3.8.4 Direct Position Specification (Solenoid Valve Mode 2) = Operation of PIO
Pattern 5
The start signal is provided for every position number. Only turning ON the relevant input
signal according to the table shown below allows the operation based on the data in the
target position number to be performed. The operation mode is called the solenoid valve
mode because solenoid valves can directly drive air cylinders. At invasion of the actuator
into the positioning width set for each position, the output signal is turned ON in the
operation of any position number or manual operation of the actuator in servo OFF status as
if a sensor were installed.
Positioning and speed change during operation are possible. Their control methods are the
same as those of other patterns.
Caution: This pattern does not allow pressing and pitch feed.
[1] Home return (ST0, HEND)
The I/O of PIO varies as shown in the table below depending on the position number before
home return.
Position No. Input Output
0
ST0 LS0
1
ST1 ⇒ JOG+
LS1
2
ST2 ⇒ Invalid LS2 ⇒ Invalid
Before home return, start signal ST0 works as JOG- moving to the home return direction
while it is set to ON and ST1 works as JOG+ while it is set to ON. By using this function,
move the actuator to a position at which home return can be done safely. The speed of ST1
is the home return speed.
After the home return is fully prepared, turn the ST0 signal ON to start the home return. At
the completion of the home return, home return complete signal HEND is turned ON. Turn
the ST0 signal OFF if HEND is turned ON. HEND remains ON unless the home is lose due
to occurrence.
If a certain home positioning precision is required, Set “Position” of position No.0 to 0 mm
and the ST0 signal is not changed by the HEND signal to remain ON. After the home return
is completed, positioning is provided for position No.0. [Refer to [3] Positioning in this
chapter]
Warning: (1) Use this pattern with Parameter No.27 “Move command type” set to “0”
(factory setting). When Parameter No.27 is set to “1”, the home return is
started as soon as the ST0 signal is turned ON and the operation cannot be
stopped even if ST0 is turned OFF.
(2) If “Position” in position No.0 is set to other than 0mm, the operation is
continued without change to provide positioning after home return.
Home Return Signal
ST0
(PLC→MCON)
If a certain precision is required. Set
“Position” of position No.0 to 0 mm and
ST0 is not chaged by HEND to remain ON.
Homing Completion Signal
HEND
(MCON→PLC)
