1.4.3 Specifications of PROFIBUS-DP Interface
Item Specification
Communication Protocol PROFIBUS-DP
Baud Rate Automatically follows the master
Communication System Hybrid System (Master-Slave System or Token Passing System)
Number of occupied stations Refer to 3.4.1 PLC Address Construction by each Operation Mode
MAX. Total Network Baud Rate Cable Type
100m 3,000/6,000/12,000kbps
200m 1,500kbps
400m 500kbps
1000m 187.5kbps
Communication Cable Length
1200m 9.6/19.2/93.75kbps
Type A Cable
Communications Cable STP cable AWG18
Connector
(Note 1)
9-pin female D-sub Connector
Transmission Path Format Bus/Tree/Star
Note 1 Please prepare a 9-pin male D-sub connector for the cable-end connector.
1.4.4 Specifications of CompoNet Interface
Item Specification
Communication System CompoNet dedicated protocol
Communication Type Remote I/O communication
Baud Rate Automatically follows the master
Communication Cable Length Follows CompoNet specifications
Slave Type Word-Mixed Slave
Available Node Addresses for Setting 0 to 63 (Setting conducted on controller parameter)
Number of occupied channels Refer to 3.4.1 PLC Address Construction by each Operation Mode
Communications Cable
(Note 1)
Round Cable (JIS C3306, VCTF2-core)
Flat cable I (with no sheathed)
Flat cable II (sheathed)
Connector (Controller Side) XW7D-PB4-R (Manufactured by OMRON or equivalent)
Note 1 Prepare separately for the communication cable.
1.4.5 Specifications of EtherNet/IP Interface
Item Specification
Communication Protocol IEC61158 (IEEE802.3)
Baud Rate 10BASE-T/100BASE-T (Autonegotiation setting is recommended)
Communication Cable Length
Follows EtherNet/IP specifications (Distance between hub and each node: 100m
max.)
Number of Connection Master Unit
Available Node Addresses for Setting 0.0.0.0 to 255.255.255.255
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 Connector × 1pc
Note 1 Prepare separately for the communication cable.
