1.4.6 Specifications of EtherCAT Interface
Item Specification
Communication Protocol IEC61158 type 12
Physical Layer 100Base-TX (IEEE802.3)
Baud Rate Automatically follows the master
Communication Cable Length
Follows EtherCAT® specifications (Distance between each node: 100m max.)
Slave Type I/O slave
Available Node Addresses for Setting
0 to 127 (17 to 80 : When connected to the master (CJ1W-NC*82) manufactured by
OMRON)
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 Connector × 2pcs (Input × 1, Output × 1)
Connect Daisy chain only
Note 1 Prepare separately for the communication cable.
1.4.7 Specifications of PROFINET-IO Interface
Item Specification
Communication Protocol IEC61158 (IEEE802.3), IEC61784
Baud Rate 100Mbps
Communication Cable Length
Distance between each segment: 100m Max.
Number of Connection Master Unit
Available Node Addresses for Setting 0.0.0.0 to 255.255.255.255
Communications Cable
(Note 1)
Category 5 or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 Connector × 1pc
GSDML File Version Ver 2.3
Note 1 Prepare separately for the communication cable.
1.4.8 Specifications of CC-Link IE Field Interface
Item Specification
Communication Protocol Conforms to IEEE802.3ab (1000BASE-T)
Baud Rate 1Gbps
Communications system Token passing
Communication Cable Length
Distance between each segment: 100m Max.
Max. number of connected units 254 (total of master and slave stations)
Max. networks 239
Communications Cable
(Note 1)
Category 5e or more
(Double shielded cable braided with aluminum foil recommended)
Connector RJ45 Connector × 2pcs
Cyclic communication
RX (slave to master) : 16384 bits
RY (master to slave) : 16384 bits
RWr (slave to master) : 8192 words
RWw (master to slave) : 8192 words
Note 1 Prepare separately for the communication cable.
