1.1.4 How to Read the Model Nameplate
[1] Main Body Case Side Surface
Model→
MODEL MCON-C-5-20PWAI-PWAI-20WAI-20WAl-3DI-N-DV-2-
0-ABB
Manufactured date →
PRODUCT DATE 2015/09/01
Manual No. →
MANUAL No. ME0341
CP INPUT DC24V 2.0A
Input power supply →
MP INPUT DC24V 7.6A
AXIS No. /OUTPUT
0 DC24V 1.2A
1
2 DC24V 1.6A
3 DC24V 1.6A
4 DC24V 0.4A
5
6
Information of the
connected axes →
(Axis No. 0 to 7)
7
CAUTION : Connect the wiring correctly and properly.
Use IAI Corporation specified cables.
Made In Japan
[2] Model Code Card
Equipment Name
Model →
MCON-C-5-20PWAI-PWAI-20WAI-20WAl-3DI-N-DV-2-0-ABB
Serial No.
Version→
Model
Version
0-0-A0-A0-NN-NN-BOA-NN
********
AXIS No. / Model / Serial No.
0 RCP5-SA4C-WA-35P-16-200-P3-S
********
1
2 RCA2-TCA4NA-I-20-4-50-A1-S
********
3 RCA2-TCA4NA-I-20-4-50-A1-S
********
4 RCD-RA1DA-I-3-2-30-D5-S
********
5
6
Information of the
connected axes
/Serial number →
(Axis No. 0 to 7)
7
