Caution: When an operation is made with jog or inching while in operation with the full
servo function, the full servo function will be inactivated. If a movement is
made again on the position number that the full servo function is set valid, the
full servo function will be activated.
6.1.1 Setting of periods taken until automatic servo OFF
Three periods from completion of positioning to automatic servo OFF can be set in the
following parameters in seconds [sec].
Parameter
No.
Name Unit Input range
Initial
value
36 Automatic servo-off delay time 1 sec 0 to 9999 0
37 Automatic servo-off delay time 2 sec 0 to 9999 0
38 Automatic servo-off delay time 3 sec 0 to 9999 0
6.1.2 Set of power-saving mode
Select a proper power-saving mode from the conditions below. Set the corresponding value
in the stop mode or parameter No.53 of the position table.
Selection is available from 0 to 3 for the servo motor type and brushless DC motor type.
Selection is available from 0 to 7 for the pulse motor type.
[Refer to 14) Stop mode in 3.3 Set of Position Table.]
Set
value
Operation after completion of positioning Selectable type
0 Servo ON not changed All type
1
Automatic servo off in a certain time (set in Parameter
No.36)
All type
2
Automatic servo off in a certain time (set in Parameter
No.37)
All type
3
Automatic servo off in a certain time (set in Parameter
No.38
All type
4 Full Servo Control Pulse motor type
5
Full-servo control for a certain time (value set in
Parameter No.36) and then automatically turning servo
OFF
Pulse motor type
6
Full-servo control for a certain time (value set in
Parameter No.37) and then automatically turning servo
OFF
Pulse motor type
7
Full-servo control for a certain time (value set in
Parameter No.38) and then automatically turning servo
OFF
Pulse motor type
Caution: y No retaining torque is provided in automatic servo OFF. Pay sufficient
attention to the setting because the actuator may be moved by external force
applied to it.
y Do not use the automatic servo OFF if the next moving command is relative
distance specification (pitch feed). Failure to follow it may cause position shift
to occur.
y Do not use the automatic servo OFF in pressing. If used, the pressing force is
lost.
y Automatic Servo OFF would not function in the operation with teaching mode
of PC software.
Chapter 6 Power-saving Function
