389
RCP2 Series
Actuator
series
Type
Feed
screw
No. of
encoder
pulses
Lead
[mm]
Mounting
direction
Minimum
speed
[mm/s]
Maximum speed
[mm/s]
Maximum acceleration
/deceleration
[G]
Minimum
push force
[N]
Maximum
push force
[N]
Rated push
speed
[mm/s]
Horizontal
380 (at 50st)
540 (at 100st)
660 (at 150st)
770 (at 200st)
860 (at 250st)
940 (at 300st)
1000 (at 350 to 550st)
980 (at 600st)
850 (at 650st)
740 (at 700st)
650 (at 750st)
580 (at 800st)
0.7
20
Vertical
25
380 (at 50st)
540 (at 100st)
660 (at 150st)
770 (at 200st)
800 (at 250 to 600st)
740 (at 700st)
650 (at 750st)
580 (at 800st)
0.2
11 39
Horizontal 0.7
12
Vertical
15
600 (at 50 to 550st)
540 (at 600st)
460 (at 650st)
400 (at 700st)
360 (at 750st)
300 (at 800st)
0.3
40 115
Horizontal 0.7
6
Vertical
8
300 (at 50 to 550st)
270 (at 600st)
230 (at 650st)
200 (at 700st)
180 (at 750st)
150 (at 800st)
0.3
70 210
Horizontal 0.7
SA6C
Ball
screw
800
3
Vertical
4
150 (at 50 to 550st)
135 (at 600st)
115 (at 650st)
100 (at 700st)
90 (at 750st)
75 (at 800st)
0.3
140 330
20
Horizontal 0.3
12
Vertical
15
600 (at 50 to 550st)
540 (at 600st)
460 (at 650st)
400 (at 700st)
360 (at 750st)
300 (at 800st)
0.2
Horizontal 0.3
6
Vertical
8
300 (at 50 to 550st)
270 (at 600st)
230 (at 650st)
200 (at 700st)
180 (at 750st)
150 (at 800st)
0.2
RCP2
(Slider
type)
SA6R
Ball
screw
800
3
Horizontal
/vertical
4
150 (at 50 to 550st)
135 (at 600st)
115 (at 650st)
100 (at 700st)
90 (at 750st)
75 (at 800st)
0.2
- - -
Chapter 10 Appendix
