395
RCA2 Series
Actuator
series
Type
Feed
screw
Motor
output
[W]
No. of
encoder
pulses
Lead
[mm]
Mounting
direction
Minimum
speed
[mm/s]
Maximum speed
[mm/s]
M
aximum acceleration
/deceleration
[G]
Minimum
push force
[N]
Maximum
push force
[N]
Rated push
speed
[mm/s]
Horizontal
240 (at 25st)
300 (at 50 to 75st)
0.3
6
Vertical
6
200 (at 25st)
300 (at 50 to 75st)
0.2
Horizontal 0.3
4
Vertical
4 200
0.2
Ball
screw
2
Horizontal
/vertical
2 100 0.2
6 6
200 (at 25st)
300 (at 50 to 75st)
4 4 200
RCA2
RCA2CR
RCA2W
(Rod
type)
Standard
type
/ Cleanroom
type
/ Dust and
drip proof
type
[Standard]
SD4NA
[Cleanroom]
[Dust and
drip proof]
SD4NB
Lead
screw
(Available
to Select
Only in
Standard
Type)
20 1048
2
Horizontal
/vertical
2 100
0.2
- - -
Horizontal 0.3
4
Vertical
4 200
0.2
Horizontal 0.3
2
Vertical
2 100
0.2
Ball
screw
1
Horizontal
/vertical
1 50 0.2
4 4 200
2 2 100
TCA3NA
TWA3NA
TFA3NA
Lead
screw
10 1048
1
Horizontal
/vertical
1 50
0.2
- - -
Horizontal
270 (at 30st)
300 (at 50st)
0.3
6
Vertical
6
220 (at 30st)
300 (at 50st)
0.2
Horizontal 0.3
4
Vertical
4 200
0.2
Ball
screw
2
Horizontal
/vertical
2 100 0.2
6 6
220 (at 30st)
300 (at 50st)
4 4 200
TCA4NA
TWA4NA
TFA4NA
Lead
screw
20 1048
2
Horizontal
/vertical
2 100
0.2
- - -
Horizontal 0.3
6
Vertical
8 300
0.2
Horizontal 0.3
4
Vertical
5 200
0.2
TA4C
TA4R
Ball
screw
10 800
2
Horizontal
/vertical
3 100 0.2
- - -
Horizontal 465 0.3
10
Vertical
13
400 0.2
Horizontal 0.3
5
Vertical
7 250
0.2
RCA2
(Table
type)
TA5C
TA5R
Ball
screw
20 800
2.5
Horizontal
/vertical
4 125 0.2
- - -
Chapter 10 Appendix
