IAI ROBO Cylinder RCP6 User Manual

14
1.3 Standard Specification RCP6-RA6C, RA7C
1.4 Built-in Controller Specification RCP6S-RA6C, RA7C
Rod
Rod Tip Adaptor
Body Frame
Bearing
Grease Supply (Φ5 hole)
(Rubber Cap)
(The same applies to the other side)
Grease Supply (Φ5 hole)
(Rubber
Cap)
Motor Unit
Screw for Motor Unit Attachment
Tapped Hole for
Ground Cable
Connection
Connector
Rod
Rod Tip Adaptor
Grease Supply (Φ5 hole)
(Rubber Cap)
(The same applies to the other side)
Grease Supply (Φ5 hole)
(Rubber Cap)
Body Frame
Screw for Motor Unit Attachment
Motor Unit
Tapped Hole for
Ground Cable
Connection
Teaching Port
Bearing
Status LED
Power · I/O Cable
Connector
Motor Side
Right Side
Opposite Side
Left Side
Motor Side
Right Side
Opposite Side
Left Side
