IAI ROBO Cylinder RCP6

15
1.5 Standard Specification RCP6-RA8C
1.6 Built-in Controller Specification RCP6S-RA8C
Rod
Rod Tip Adaptor
Grease Supply (Φ5 hole)
(Rubber Cap)
(The same applies to the other side)
Grease Supply (Φ5 hole)
(Rubber Cap)
Body Frame
Motor Cover
End Cover
Tapped Hole for
Ground Cable
Connection
Teaching Port
Bearing
Status LED
Power · I/O Cable
Connector
Rod
Rod Tip Adaptor
Grease Supply (Φ5 hole)
(Rubber Cap)
(The same applies to the other side)
Grease Supply (Φ5 hole)
(Rubber Cap)
Body Frame
Motor Cover
End Cover
Tapped Hole for
Ground Cable
Connection
Bearing
Connector
Motor Side
Right Side
Opposite Side
Left Side
Motor Side
Right Side
Opposite Side
Left Side
