IAI ROBO Cylinder RCP6 User Manual

16
2. Side-Mounted Motor Type
2.1 Standard Specification RCP6-RA4R
2.2 Built-in Controller Specification RCP6S-RA4R
Rod
Rod Tip Adaptor
Grease Supply (Φ2.5 hole)
(Hexagonal Socket Head Bolt)
(The same applies to the other side)
Body Frame
Motor Cover
End Cover
Pulley Cover
Bearing
Tapped Hole for Ground
Cable Connection
Rear Bracket
Connector
Rod
Rod Tip Adaptor
Grease Supply (Φ2.5 hole)
(Hexagonal Socket Head Bolt)
(The same appli
es to the other side)
Body Frame
Motor Cover
End Cover
Pulley Cover
Bearing
Tapped Hole for Ground
Cable Connection
Rear Bracket
Status LED
Teaching Port
Power · I/O Cable
Connector
Motor Side
Right Side
Opposite Side
Left Side
Motor Side
Right Side
Opposite Side
Left Side
