Troubleshooting 6-25
ICE Vulcan Service Manual
E5039
SupplySensor
‘Label Supply Sensor Fault’ - The
label supply sensor is not working.
This could be due to a faulty or
damaged sen- sor, or faulty or dam-
aged wiring, or a loose connector.
• Power off the machine and check
wiring and connections, then re-try.
• You can check the sensor input
at Tools > Diagnostics > Printhead
>Inputs.
• If the problem persists, or you
wish to pur- chase a spare label
supply sensor, please call your
local service representative. The
machine will not run until this
fault is resolved. Once resolved
and ready, press the ‘Clear’ button
below.
Fault
E5040
IntegraPrintheadRatio ‘Printhead
Positioning Error’ - Check that the
printhead, print roller and bumpers
are fitted.
• If everything is fitted correctly
and the prob- lem persists, check
the Printhead Position Sensor at
Tools > Diagnostics > Printhead >
Inputs.
• If no input is detected and the
problem per- sists, please call your
local service repre- sentative. Once
resolved and ready, press the
‘Clear’ button below.
Fault
E5041
IntegraLabelDrive
TemperatureShutdown ‘Label Drive
Fault’ - The label drive fault may be
caused by a faulty main circuit
board, or the ribbon motors, or the
connections between them.
• Power off the machine
and check the connections,
then re-try.
• If the problem persists, call your
local ser- vice representative. The
machine will not run until this fault
is resolved. Once resolved and
ready, press the ‘Clear’ button
below.
Fault
Table 6-5: CLARiTY Error Messages (Continued)
