OTHER FUNCTIONS
7-40
• D-STAR RX Call sign
Command: 20 0001, 20 0002
!1 ~ !4q, w e ~ !0
@3 ~ #0 #1 ~ #8!5 ~ @2
• • • • • •
X X X XX XX X X X
X X
• • •
X XX X X XX X
• • • • • •
X XX X
q
Header flag data (First byte)
Data Description
bit7 0 (Fixed) —
bit6 0 (Fixed) —
bit5 0 (Fixed) —
bit4 0/1 0=Voice, 1=Data
bit3 0/1 0=Direct, 1=Through repeater
bit2 0/1 0=No Break-in, 1=Break-in
bit1 0/1 0=Data, 1=Control
bit0 0/1 0=Normal, 1=EMR
w
Header flag data (Second byte)
Data
Description
bit2 bit1 bit0
1 1 1 Repeater control
1 1 0 Send auto acknowledge
1 0 1 (Not used)
1 0 0 Request to re-transmit
0 1 1 Send acknowledge
0 1 0 Receive no reply
0 0 1 Repeater disabled
0 0 0 NULL
e
~
!0
: Call sign of the CALLER station (8 characters)
!1
~
!4
: Note of the CALLER station (4 characters)
!5
~
@2
: CALLED station's call sign (8 characters)
@3
~
#0
: RXRPT1's call sign (8 characters)
#1
~
#8
: RXPRT2's call sign (8 characters)
L FF: No signal has been received since the power was turned ON.
L Refer to the next page for
CALLER, CALLED, RXRPT1 and RXPRT2.
■ CI-V information
D Commands (Continued)
