Icom ID-51A Advanced Instructions

2
USING A microSD CARD
2-8
Save with a different file name (Continued) ■
Push D-pad( u ) to move the cursor to the second
digit.
Repeat steps i y and u to enter a name of up to
14-characters, including spaces.
(Example: My Data)
After entering the name, push D-pad(Ent). o
• After pushing D-pad(Ent), “Save le?” appears.
D-pad
(�)
(Ent)
!0 Push D-pad() to select “YES,” and then push D-
pad(Ent) to save the setting file.
• While saving, a progress bar is displayed, then the “SD
CARD” screen appears after the save is completed.
!1 Push [MENU] to exit the MENU screen.
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
