Icom ID-51A Advanced Instructions

1
ACCESSORY ATTACHMENT
1-3
Belt clip ■
To attach the belt clip:
Remove the battery pack from the transceiver, if it is q
attached. (p. 1-2)
Slide the belt clip in the direction of the arrow until the w
belt clip locks in place, and makes a ‘click’ sound.
To detach the belt clip:
Remove the battery pack from the transceiver, if it is q
attached. (p. 1-2)
Lift the tab up ( w q), and slide the belt clip in the direc-
tion of the arrow (w).
■ Hand strap
To facilitate carrying the transceiver, slide the hand
strap through the loop on the top of the rear panel, as
illustrated to the right.
Hand strap
q
w
Tab
Belt clip
To attach To detach
Battery pack
or battery case
Previous view

Icom ID-51A Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Antenna Connector	SMA
GPS Receiver	Yes
Waterproof	IPX7
Modes	FM, DV
Weight	255 g
Memory Channels	1304 channels
Output Power	5W (High), 2.5W (Middle), 0.5W (Low)
