16
MENU SCREEN
16-33
GPS Indicator (Default: ON)
GPS > GPS Set > GPS Indicator (GPS Indicator)
Select whether or not to display the GPS icon(
).
• OFF : The GPS icon is not displayed.
• ON : The GPS icon appears* when valid position data is received, and
blinks when no position data is received.
Selected GPS
receiver
Not connected
Connected/
Searching
Connected/
Received
Internal GPS – Blinks Appears
External GPS Not displayed Blinks Appears
*No icon appears when “Manual” is selected in the GPS select item.
Position Format (Default: ddd°mm.mm')
GPS > GPS Set > Position Format (Position Format)
Select either the ddd°mm.mm’ or ddd°mm’ss" format to display position in-
formation.
Altitude/Distance Units (Default: ft/ml*)
GPS > GPS Set > Altitude/Distance Units (Altitude/Distance Units)
Select either the meter or feet/mile format to display the distance and alti-
tude.
*The default setting may differ, depending on the transceiver’s version.
Speed Units (Default: mph*)
GPS > GPS Set > Speed Units (Speed Units)
Select either the km/h, mph or knots format to display the speed.
*The default setting may differ, depending on the transceiver’s version.
GPS Out (Default: OFF)
GPS > GPS Set > GPS Out (GPS Out)
Select whether or not GPS information from either the internal or external
GPS receiver is output at the [DATA] jack.
For your information ✓
No data is output when “OFF” or “Manual” is selected in the GPS Select
item.
Select “OFF” when you want to operate slow-speed data communication.
GPS items (Continued) ■
