19
SPECIFICATIONS
19-2
■ Transceiver
D General
• Frequency coverage : (unit: MHz)
EUR, KOR
TX 144–146, 430–440
RX 144–146, 430–440
UK
TX 144–146, 430–440
RX 108–174*
1
, 380–479*
2
ITR
TX 144–146, 430–434, 435–438
RX
108–136.995,*
1
144–146,
430–434, 435–438
U.S.A.
TX 144–148, 430–450*
3
RX 108–174*
4
, 380–479*
3
EXP
TX 137–174*
4
, 400–479*
2
RX 108–174*
4
, 380–479*
2
EXP-1
TX 144–148, 430–440
RX 108–174*
4
, 380–479*
2
ALL RX
BC Radio (AM): 0.520–1.710 kHz
BC Radio (FM): 76.0–108.0 MHz*
5
*
1
Guaranteed 144–146 MHz only
*
2
Guaranteed 430–440 MHz only
*
3
Guaranteed 440–450 MHz only
*
4
Guaranteed 144–148 MHz only
*
5
88.0–108.0 MHz for the USA version transciever.
The SUB band audio signal may be muted, depending on
the combination of operating band and mode.
• Mode :
FM, AM (Rx only), DV
• Number of memory channels
:
554
(incl. 50 scan edges and 4 call channels)
• Number of BC radio memory channels
:
500
• Usable temp. range : –20°C to +60°C; –4°F to +140°F
• Tuning steps :
1, 5, 6.25, 8.33, 9, 10, 12.5, 15, 20,
25, 30, 50, 100, 125 and 200 kHz
* The selectable steps may differ, depending on the selected fre-
quency band or operating mode.
• Frequency stability : ±2.5 ppm
(–20°C to +60°C; –4°F to +140°F)
• Power supply : 10.0–16.0 V DC for external DC
power, or specified Icom’s battery
pack
•
Digital transmission speed
: 4.8 kbps
• Voice coding speed : 2.4 kbps
• Current drain
(at 7.4 V DC) :
TX (at 5 W) Less than 2.5 A
RX Max. output FM Less than 350 mA
(Internal speaker)
Less than 200 mA (External speaker)
DV Less than 450 mA (Internal speaker)
Less than 300 mA (External speaker)
• Antenna connector : SMA (50 W)
• Dimensions : 58(W)×105.4(H)×26.4(D) mm;
(projections not included) 2.3(W)×4.1(H)×1.0(D) in
• Weight
(approximately) : 255 g; 9 oz
(incl. battery pack and antenna)
D Transmitter
• Modulation system :
FM Variable reactance freq.
modulation
DV GMSK reactance freq.
modulation
• Output power
(at 7.4 V DC) :
High 5.0 W, Mid. 2.5 W,
Low2 1.0 W, Low1 0.5 W,
S-Low 0.1 W (Typical)
•
Max. frequency deviation
: ±5.0 kHz (FM wide: approx.)
±2.5 kHz
(FM narrow: approx.)
• Spurious emissions : Less than –60 dBc at High/Mid.
Less than –13 dBm at Low2/
Low1/S-Low
• Ext. mic. impedance : 2.2 kW
D Receiver
• Receive system : Double-conversion
superheterodyne
• Intermediate frequencies
A Band : 46.35 MHz (1st IF)
: 450 kHz (2nd IF)
B Band : 61.65 MHz (1st IF)
: 450 kHz (2nd IF)
• Sensitivity
(except spurious points)
FM (1 kHz/3.5 kHz Dev.; 12 dB SINAD)
:
Less than –15 dBµ
DV
(PN9/GMSK 4.8 kbps; BER 1%)
:
Less than –11 dBµ
• Audio output power (at 10% distortion)
Internal speaker :
More than 0.4 W with a 16 Ω load
External speaker : More than 0.2 W with a 8 Ω load
• Selectivity
FM
(Wide) : More than 55 dB
FM
(Narrow), DV : More than 50 dB
•
Ext. speaker connector
: 3-conductor 3.5(d) mm; (
1
⁄8˝)/8 W
• Spurious and image rejection ratio
: More than 60 dB
• Squelch Sensitivity
(threshold, 1 kHz/3.5 kHz Dev.)
: Less than –15 dBµ
■ BC-202 d e s k t o p c h a r g e r
•
Power supply requirement
: 12 to 16 V DC or the specified
Icom AC adapter (BC-123S)
•
Charging temperature range
: 0˚C to +40˚C; +32˚F to +104˚F
• Weight : Approximately 104 g; 3.7 oz
(without AC adapter)
• Dimensions : 88(W)×72.6(D)×46.5(H) mm;
3.5(W)×2.9(D)×1.8(H) in.
(projection is not included)
All stated specifications are subject to change without notice
or obligation.
