IDEC SmartRelay functions
194 IDEC SmartRelay Manual
• Current Character Set: which character set is selected for
the display of message texts
Note
Message texts supported by IDEC SmartRelay FL1D will display on
the Text Dispaly only when the following conditions are met:
- CharSet1 is selected and set to ISO8859-1
- Current Character Set "CurrCharSet" is set to CharSet1
Of the fifty possible message texts that you can configure,
you can select any number of them to be from the first
language and any number from the second language. For
example, you could configure fifty message text function
blocks that have a single message text for Character Set 1.
Alternatively, you could configure twenty-five message text
function blocks, each of which has two message texts: one
for Character Set 1 and one for Character Set 2. Any
combination is valid such that the total does not exceed fifty.
Within a single message text, the text must be from one
character set. You can edit message texts in any of the
supported character sets from WindLGC. From the IDEC
SmartRelay base module, you can only edit text using
characters from the ISO8859
-1 character set.
The language and therefore character set of a message text
is independe
nt of the language setting for the IDEC
SmartRelay display menus. They can be different.
Character
Set in IDEC
SmartRelay
Common
Name
Supports
Languages
Internet Reference
ISO8859-1 Latin-1 English,
German, Italian,
Spanish (partly),
Dutch (partly)
http://en.wikipedia.org/
wiki/ISO/IEC_8859-1
ISO8859-5 Cyrillic Russian http://en.wikipedia.org/
wiki/ISO/IEC_8859-5
ISO8859-9 Latin-5 Turkish http://en.wikipedia.org/
wiki/ISO/IEC_8859-9
ISO8859-16 Latin-10 French http://en.wikipedia.org/
wiki/ISO/IEC_8859-16
GB-2312 Chinese Chinese http://en.wikipedia.org/
wiki/GB2312
Shift-JIS Japanese Japanese http://en.wikipedia.org/
wiki/Shift_JIS
