• Set Param
For information on the various parameters, refer to the
Chap
ters 5.1.1 to 5.1.3.
•Set..
For information on the various settings, refer to Chapter 5.2.
•
Prg Name
This menu command only allows
you to read the na
me of
your circuit program. It is not possible to modify this name in
parameter assignment mode (see Chapter 3.6.4).
5.1.1 Parameters
Note
In the following discourse on parameters, we presume that the
respective default parameter protection mode (“+”) has been
maintained. This is a prerequisite for viewing and editing
parameters in the parameter assignment mode! See Chapter 4.3.5
and the example on Page 90.
Parameters are, for example:
• The delay times of a timer relay.
• The switching times (cams) of a timer switch.
• Counter thresholds
• The monitoring time for hour counters
• The trigger thresholds.
Each one of the parameters is identified by its block number
(Bx)
and the
shortname of the parameter. Examples:
• T:...is a configurable time.
• MI:...is a configurable time interval.
Note
WindLGC also allows you to assign names to blocks (for more in-
formation, refer to Chapter 7).
