Programming IDEC SmartRelay
IDEC SmartRelay Manual 69
3.6 Writing and starting the circuit program
After you have designed a circuit, you want to write it to your
IDEC SmartRelay. The small example below shows how to
do this.
3.6.1 Selecting programming mode
You have connected IDEC SmartRelay to the power supply
and switched it on. The display now shows you the message:
No Program
Press ESC
Switch IDEC SmartRelay to programming mode by pressing
ESC. This will take you to the main menu of IDEC
SmartRelay:
>Program..
Card..
Setup..
Start
IDEC SmartRelay’s main menu
The first character in the first line is the ”>” cursor. Press
and
to move the ”>” cursor up and down. Move it to
”Program..” and confirm with OK. IDEC SmartRelay opens
the programming menu.
>Edit..
Clear Prg
Password
Msg Config
IDEC SmartRelay’s programming
menu
Here you can also move the ”>” cursor by pressing and .
Move the ”>” cursor to ”Edit..” and confirm with OK.
>Edit Prg
Edit Name
AQ
Memory?
The Edit menu of IDEC SmartRelay
