Applications
286 IDEC SmartRelay Manual
8.5.1 Requirements for a gate control system
• Every gate is opened and closed by means of a
cord-operated switch. The gate is will be fully opened or
fully closed.
• All gate can be opened and closed locally by means of
pu
shb
uttons.
• The gate can be opened and closed at the gatehouse by
means of th
e bus system. The GATE OPEN or GATE
CLOSED status is indicated.
• An indicator lamp is switched on five seconds before the
g
ate star
ts moving and when the gate is in motion.
• A safety pressure bar prevents harm to persons and
objects fro
m getting trapped or damaged when the gate
closes.
Wiring of the gate control system with FL1E-H12RCC and CM AS-
Interface
