IDEC SmartRelay Manual 233
5
Configuring IDEC SmartRelay
Parameter assignment refers to the configuration of the
block parameters. You can set delay times for time
functions, the switching times of timers, counter threshold
values, the monitoring interval of an operating hours counter,
the on and off thresholds of the trigger, and more.
You can configure the parameters
• In programming mode
• In parameter assignment mode
In programming mode, the author of the circuit program also
sets
the paramet
ers
Parameter assignment mode allows the editing of
parameter
s without having to modify the circuit program.
This feature is available so that you can edit parameters
without having to change to programming mode. The
advantage: The circuit program remains protected, but can
be adapted by the user to meet specific requirements.
Note
In parameter assignment mode, IDEC SmartRelay continues exe-
cution of the circuit program.
