IDEC SmartRelay functions
128 IDEC SmartRelay Manual
4.4 Special functions list - SF
When you create your circuit program in IDEC SmartRelay,
you find the special function blocks in the SF list.
You can invert the inputs of SFs individually, that is, the
circu
it program converts a logical ”1” at the input into a
logical ”0”; a logical ”0” it converts into a logical ”1”. An
example of the program code is found in Chapter 3.6.3.
The table also specifies whether the
relevant fun
ction can be
set retentive (Rem). The following SFs are available:
View in IDEC SmartRelay Name of the special function Rem
Times
On-delay
(see page 131)
REM
Off-delay
(see page 135)
REM
On-/Off-delay
(see Page 136)
REM
Retentive on-delay
(see page 138)
REM
Interval time-delay relay/Pulse
output
(see page 139)
REM
Edge-triggered interval time-
delay relay
(see page 140)
REM
Asynchronous pulse
generator
(see Page 142)
REM
Random generator
(see page 144)
