Programming IDEC SmartRelay
68 IDEC SmartRelay Manual
3.5 Overview of IDEC SmartRelay menus
Programming mode
Parameter assignment mode
Parameter assignment menu
>Stop
Set Param
Set..
Prg Name
For more details on these menus, refer to Appendix D.
The Text Display menus provide configuration settings for
the Text Display. Thes
e menus are a subset of the IDEC
SmartRelay menus and are operated in much the same way.
Appendix section D.2 shows the Text Display menus.
>Program..
Card..
Setup..
Start
>Edit..
Clear Prg
Password
Msg Config
> Card
Card
CopyProtect
= IDEC
SmartRelay
>Clock
LCD
Menu Lang
BM AI NUM
Main Menu
Programming menu
OK
ESC
OK
ESC
Transfer menu
Setup menu
Note: The ‘BM AI NUM’ selection is
only available on base modules that
support four analog inputs.
OK
ESC
